3 Insert the hooks on the wall mounting
adaptor into holes (
1 ) and ( 2 ) on the
base unit.
1 2
1
2
4
Adjust the adaptor to hold the base unit,
then push it in the direction of the arrow
until it clicks into place.
5
Mount the unit on a wall then slide down
to secure in place.
1 AC adaptor cord
R This product is compliant with the
following wall phone plate sizes (2
types).
2 83 mm (3 1 / 4 inches)
3 102 mm (4 inches)
Fit the slots of the unit onto the
corresponding wall phone plate tabs
for (
4 ) and ( 5 ) respectively.
1
5
4
2 3
4
5
