Specifications
§ MPEG-1 Layer 3, MPEG-2 Layer 3
≥ Specifications are subject to change without notice.
Mass and dimensions are approximate.
≥ Total harmonic distortion is measured by a digital spectrum analyzer.
AMPLIFIER SECTION
RMS Output Power Stereo mode
Front Ch (both ch driven) 20 W per channel (6 ≠),
1 kHz, 10 % THD
Total RMS Stereo mode power 40 W
TUNER SECTION
Preset Memory FM 30 stations
AM 15 stations
Frequency Modulation (FM)
Frequency range 87.50 MHz to 108.00 MHz
(50 kHz step)
Antenna terminals 75 ≠ (unbalanced)
Amplitude Modulation (AM)
Frequency range 522 kHz to 1629 kHz
(9 kHz step)
520 kHz to 1630 kHz
(10 kHz step)
DISC SECTION
Disc played [8 cm or 12 cm]
CD, CD-R/RW
(CD-DA, MP3
§ )
Pick up
Wavelength 790 nm
Laser power CLASS 1, CLASS 1M
[NORSK]
Bølgelengde
790 nm
Laserstyrke Klasse 1, Klasse 1M
Ingen farlig stråling sendes ut
(med sikkerhets-beskyttelse)
Audio Output (Disc)
Number of channels FL, FR, 2 ch
SPEAKER SECTION
[HC55]
Type 2 way, 2 speaker system
(Passive Radiator)
Speaker unit(s)
Woofer 6.5 cm Cone typek1 per
channel
Tweeter 1.5 cm Piezo typek1 per
channel
Passive Radiator 8 cmk2 per channel
Impedance 6 ≠
[HC35]
Type 1 way, 1 speaker system
(Passive Radiator)
Speaker unit(s)
Full range 6.5 cm Cone typek1 per
channel
Passive Radiator 8 cm k2 per channel
Impedance 6 ≠
[HC55] BLUETOOTH SECTION
Bluetooth ® system specification V2.1 + EDR
Wireless equipment
classification
Class 2 (2.5 mW)
Supported profiles A2DP, AVRCP, HFP
Frequency band 2402 MHz to 2480 MHz
(Adaptive Frequency
Hopping)
Driving distance 10 m Line of Sight
(iPhone 4, at height 1 m, in
“MODE 1”)
TERMINAL SECTION
Phone jack
Terminal Stereo, ‰3.5 mm jack
AUX (Rear)
Terminal Stereo, ‰3.5 mm jack
USB Port
USB Standard USB 2.0 full speed
Media file format support MP3 (¢.mp3)
USB device file system FAT12, FAT16, FAT32
USB port power Max 500 mA
GENERAL
Power consumption 28 W
Power consumption in standby mode
Approx. 0.2 W
Power supply AC 220 V to 240 V, 50 Hz
Dimensions (WkHkD) With stand
480 mmk194 mmk84 mm
Without stand
480 mmk194 mmk69 mm
Mass Approx. 2.4 kg
Operating temperature range 0 oC to r40 oC
Operating humidity range 35 % to 80 % RH
(no condensation)
