. ACCESSORIES

Use only bits suitable for size of drill’s chuck.
Use Panasonic original Optional Keyless drill chuck (EY9X003E) and Quick change chuck
(EY9HX110E) for maximum performance.

. SPECIFICATIONS

MAIN UNIT

KEYLESS DRILL CHUCK

BATTERY PACK

BATTERY CHARGER

Note: This chart may include models that are not available in your area.

Please refer to the catalogue.

CAUTION: This Panasonic Multi Drill & Driver is designed to use only battery pack type EY9230,

EY9136. Use with other battery pack type may damage the tool and the battery, and may
result in the risk of fire and personal injury.

Model

EY6535

Drill driver Mode

Impact mode

(Caution: Do not use Keyless drill chuck for impact mode)

Maximun

recommen

ded

capacities

Drilling

Wood drilling

ø 27 mm (1 - 1/16")

Not feasible

Metal drilling

ø 13 mm (1/2")

Screw

driving

Machine screw

Not feasible

Wood screw

ø 6.8 mm (17/64")

Tech screw

ø 6 mm (15/64")

Coach screw (Lag bolt)

ø10 mm (3/8")

Bolt Fastening

Not feasible

Standard Bolt: M12

High Tensile Bolt: M10

No load speed

0 - 650 /min (rpm)

0 - 2200 /min (rpm)

Max Torque

22.6 Nm (230 kgf-cm)

127.5 Nm (1300 kgf-cm)

at high tensile bolt fastening

Clutch Torque

Approx.

1.0 Nm (10 kgf-cm, 8.7 in-lbs.) -

5.4 Nm (55 kgf-cm, 47.7 in-lbs.)

Impact per minute

0 - 3300 /min (ipm)

Motor

DC Motor 15.6V

Square drive

12.7 mm (1/2") square drive with ball detent

Weight (with battery pack)

2.2 kg ( 4.8 lbs.)

Overall length

216 mm ( 8 - 1/2")

Model

EY9X003E

Chuck Capacity

1.6 mm - 13 mm (1/16" - 1/2")

Model

EY9230

Storage battery

Ni-MH Battery

Battery voltage

15.6V DC (1.2V x 13 cells)

Model

EY0110

Electrical rating

See the rating plate on the bottom of the charger.

Weight

0.78 kg, (1.72 lbs.)

Charging Time

7.2 V

9.6 V

12 V

15.6 V

18 V

24 V

1.2Ah

EY9065, EY9066 EY9080, EY9086 EY9001, EY9006

1.7Ah

EY9180, EY9182

EY9101

2.0Ah

EY9168

EY9106

EY9136

EY9117

3.0Ah

EY9200

EY9230

EY9210

3.5Ah

EY9201

EY9231

EY9251

20min.

25min.

30min.

60min.

45min.

90min.

55min.

65min.
