Operators Manual
ALS 230
Release 11/05 Page 76 Technical Specification
Description Details
Power consumption 300 VA
Mains voltage 100V~, 115V~, 200V~ and 230V~ 50/60Hz (6.3A for 110V else
3.15A),
+5%- 10%
10.2 Application specification
The labeller is designed and built for automatic applies of self-adhesive labels.
10.3 APSF- Sensor Specification (Optional function)
The resolution of the sensor should be selectedsuch per 1mm product movement 1 to 5 pulses
are generated.
It is possible to use one common sensor for several dispensers. In this case the sensor is
supplied from one machine or the several supply voltages switched parallel are separated with
diodes.
Supply voltage: 24 V DC
Output current: 20mA for each dispenser
Signal rise and fall time: each 1
µs
Max frequency: 20 kHz
Signal ratio: 1:1 +- 12,5 %
Connection: Only shielded cable. The shield has to be grounded on both sides.
