Page 8

MULTITASKER
400-0433-003
7
DIAGRAM 3: SWITCH SETTINGS
EQ2
SW3
GAIN2
SW5
EQ1
GAIN1
SW4
SW6
Set SW6 to SW for software control and HW for a fixed gain = 1.
Set SW5 to SW for software control and HW for a fixed gain = 1.
Set SW4 to SW for software control and HW for hardware control.
Set SW3 to SW for software control and HW for hardware control.
DESCRIPTION
1
2
1
2
INPUT
Video Gain
Video Equalization
CONTROL
