NV3000/5000/6000(EXP)/7000H User Manual
24
Pin # Definition Pin # Definition
1 Sensor input signal 1+ 11 Relay Normal Close 1
2 Sensor output signal 1-(GND) 12 Relay Common 2
3 Sensor input signal 2+ 13 Relay Normal Open 2
4 Sensor output signal 2-(GND) 14 Relay Normal Close 2
5 Sensor input signal 3+ 15 Relay Common 3
6 Sensor output signal 3-(GND) 16 Relay Normal Open 3
7 Sensor input signal 4+ 17 Relay Normal Close 3
8 Sensor output signal 4-(GND) 18 Relay Common 4
9 Relay Common 1 19 Relay Normal Open 4
10 Relay Normal Open 1 20 Relay Normal Close 4
2.13 The Sensor input and Relay output Specifications
You may use the sensor input and relay output specifications table below for your reference.
A. Sensor Input Specification
Absolute Maximum Ratings (Ta=25°C)
Parameter Symbol Rating Unit
Forward Current I
F
50 mA
Reverse Voltage V
R
6 V Input
Power Dissipation P 70 mW
Electrical/Optical Characteristics (Ta=25°C)
Parameter Symbol Min Typ. Max. Unit Conditions
Forward Current V
F
- 1.2 1.4 V I
F
=20mA
Reverse Voltage I
R
- - 10 A V
R
=4V
Input
Terminal Capacitance C
t
- 30 250 pF V=o, f=1KHz
Parameter Symbol Min Typ. Max. Unit Conditions
Collector Dark Current I
CEO
- - 100 nA V
CE
=20V
Collector-Emitter
Breakdown Voltage
BV
CEO
35 - - V I
C
=0.1mA
O
utput
Emitter-Collector
Breakdown Voltage
BV
ECO
6 - - V I
E
=10 A
*Current Transfer Ratio CTR 50 - 600 %
Collector Current I
C
2.5 - 30 mA
I
F
=5mA, V
CE
=5V R
BE
=
Collector-Emitter
Breakdown Voltage
V
CE(sat)
- 0.1 0.2 V I
F
=20mA, I
C
=1mA
Isolation Resistance R
ISO
5 x 10 10 10 11 - DC500V, 40-60% R.H.
Floating Capacitance C
f
- 0.6 1.0 pF V=0, f=1MHz
Cut-off Frequency f
c
- 80 KHz
V
CE
=5V, I
C
=2mA
R
L
=100, -3dB
Response Time (Rise) t
r
- 4 18 s
T
rans
fer
Char
ac
ter
is
tic
s
Response Time (Fall) t
f
- 3 18 s
V
CE
=2V, I
C
=2mA
R
L
=100
I
C *CTR=
I
F
100%
B. Relay Output Specification
Surge strength :1500 VAC
Nominal power : 200mw ~ 360mw
Operating power : 110mw ~ 200mw
