45
Optional components
Optional components
Connecting audio
components
Depending on the equipment to be connected and
the method of connecting, select one of the
following connections. Refer to the instructions of
each component.
Connecting an MD deck for
digital recording
You can record from CD into the MD deck
digitally by connecting an optical cable.
Connecting an MD deck for
analog recording
Make sure to match the color of the plugs and the
connectors. To listen to the sound of the connected
MD deck, press FUNCTION repeatedly until
“MD” appears.
To the digital input of the MD deck
To the audio output of
the MD deck To the audio input of
the MD deck
continued
