Page 15
GB - 15
Scraper Blade
The scraper blade allows the back of the
housing to keep better contact with the surface
being cleared. It also prevents damage to the
housing from normal wear.
IMPORTANT: DO NOT allow Scraper Blade to
wear too far or Auger/Impeller housing will
become damaged.
Runners
The runners control the distance between the
scraper blade and the ground. Adjust runners
equally to keep blade level with the ground.
Refer to Pre-Start for recommended settings.
Drift Cutters
Drift cutters break up snow drifts that are taller
than the auger housing and direct the snow
into the auger. Store the drift cutters on the
auger housing when not in use. Install them as
shown below so they are taller than the snow
to be cleared.
FILLING FUEL TANK
Fuel Shut-Off Valve
IMPORTANT: The fuel shut-off valve MUST be
in the closed position prior to transporting the
unit.
The fuel shut-off valve has two positions:
• Closed Position: Use this position to
service, transport, or store the unit.
• Open Position: Use this position to run the
unit.
To add fuel to fuel tank:
1. ALWAYS place unit in open or well-
ventilated area.
2. Stop engine and allow to cool.
3. Clean Fuel Cap and surrounding area to
prevent dirt from entering Fuel Tank.
4. Remove Cap.
IMPORTANT: DO NOT use gasohol or
gasoline containing alcohol. See Engine
Manual for correct type and grade of fuel.
5. Fill fuel tank to within 1/2 in. (1.2 cm)
below bottom of filler neck with unleaded
gasoline.
NOTE: Tank capacity is 1 gallon (3.8 liters).
6. Replace Fuel Cap and tighten.
7. ALWAYS clean up any spilled fuel.
PRE-START
1. Frozen Impeller
IMPORTANT: Before starting engine, check
impeller to be sure it is not frozen.
To check impeller:
1. With key in “Stop” position, squeeze
Attachment Clutch Lever to Engaged
position.
2. Pull Recoil Starter Handle.
3. If Impeller is frozen, (cannot pull Starter
Handle) move unit to a heated area and
thaw to prevent possible damage.
2. Check Function of Clutches
If clutches do not engage or disengage
properly, adjust or repair before operation (see
Service and adjustments).
1. Stored Position
2. Operating Position
WARNING: AVOID INJURY. Read
and understand the entire Safety
section before proceeding.
