Chapter 1. Introduction

9

No.

Component

Description

1

USB 2.0
Hub

USB peripherals (printers, scanners, etc.) can plug into this/
these port(s) (this may require an extra power adapter).

2

Console
Port Section

CS1762

A

– The cables from your DVI monitor, speakers, and

microphone plug in here. Each connector is marked with an
appropriate icon to indicate itself.
Note: The CS1762

A

’s console USB keyboard and USB

mouse ports are located on the unit’s front panel.
CS1764

A

– The cables from your DVI monitor, USB

keyboard, USB mouse, speakers, and microphone plug in
here. Each connector is marked with an appropriate icon to
indicate itself.

3

KVM Port
Section

The cables that link the switch to your computers plug in
here. Each KVM port section is comprised of a microphone
jack, speaker jack, USB type B socket and a DVI connector.

4

Power Jack

The power adapter cable plugs into this jack.
