Sony AVD-C70ES User Manual
Avd-c70es, Front view, Back view
AVD-C70ES
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
FRONT VIEW
CD/DVD
Receiver
120VAC
60Hz
BACK VIEW
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
SIDE VIEW
16 3/4"
1/2"
12 "
5 1/4 "
4 3/4 "
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
9 3/4 "
1 3/4 "
