Introduction
Connection Ports
1. USB Connector
2. HDMI Connector
3. DVI Input Connector
4. VGA Input Connector (PC Analog Signal)
5. Component Video Input Connector
6. S-Video Input Connector
7. RS232 Connector
8. Kensington
TM
Lock Port
9. VGA Output Connector (Monitor Loop-through Output Connec-
tor)
10. Power Socket
11. Audio Input Connector
12. Composite Video Input Connectort
USB
HDMI
DVI
VGA-IN
Pr/Cr Pb/Cb
Y
S-VIDEO
VIDEO
AUDIO-IN
VGA-OUT
RS-232
5
6
4
3
2
1
7
8
10
9
11
12
