AT-iMG616RF/RF+ Series Multiservice VoIP Gateway - User Manual 21
Appendix B: Technical Specifications
6.1. Product Specifications AT-iMG616RF/RF+
Supported standards
IEEE 802.3 10 BASE-T, 100 BASE-TX
IEEE 802.3u 100 BASE-FX,
RFC 791, RFC1144, RFC1112, RFC2236, RFC 2516,
RFC 1334, RFC 1994, RFC 1631, RFC 2131,
RFC 3261, RFC 1350, RFC 318, RFC 826,
RTP/RTCP, H.323 4.0, MGCP/NCS 1.0, SNMP v1
Interface
WAN port 1 100BASE-FX (SC connector)
LAN port 6 10/100BASE-TX (8 pin RJ45 connector)
TEL port 2 FXS (6 pin RJ11 connector)
TV port (IN) 1 SC connector
TV port (OUT) 1 female 75-ohm F-type connector
Power
AC Input voltage AC100-240V
Standard Frequency 50-60Hz
AC Input current 0.1A (240V)
Average power 10W
Average heat 7.0kcal/h
Environment condition
Storage Temperature -20° to 70°C
Humidity Less than 95% (non condensing)
Operating Temperature 0° to 40° C
Humidity Less than 80% (non condensing)
Size (with no projection)
240(W) x 150 (D) x45 (H) mm
Weight
400g
MAC address table size
1024
Memory Capacity
RAM memory 16Mbyte
Flash memory 4Mbyte
Product Certification
CE
Compliances
IEC60950, EN60950
EN55022, EN61000-3-2, EN61000-3-3, EN55024
Class 1 Laser Product, IEC825
