Additional Information
DCR-HC32/HC42 2-584-906-11(1)
Input/Output connectors
Audio/Video
input/output
10-pin connector
Input/output auto switch
Video signal: 1 Vp-p, 75 Ω
(ohms), unbalanced
Luminance signal: 1 Vp-p,
75 Ω (ohms), unbalanced
Chrominance signal:
0.286 Vp-p, 75 Ω (ohms),
unbalanced
Audio signal: 327 mV (at
output impedance more than
47 k Ω (kilohms)), Input
impedance more than 47 k Ω
(kilohms), Output impedance
with less than 2.2 k Ω
(kilohms)
LANC jack Stereo mini-minijack (Ø 2.5
mm)
LCD screen
Picture DCR-HC32:
6.2 cm (2.5 type)
DCR-HC42:
6.9 cm (2.7 type, aspect ratio
16:9)
Total dot number 123 200 (560 × 220)
General
Power
requirements
DC 7.2 V (battery pack)
DC 8.4 V (AC Adaptor)
Average power
consumption
DCR-HC32:
During camera recording using
the viewfinder 2.1 W
During camera recording using
the LCD 2.5 W
During camera recording using
the viewfinder and the LCD
2.6 W
DCR-HC42:
During camera recording using
the viewfinder 2.6 W
During camera recording using
the LCD 3.0 W
During camera recording using
the viewfinder and the LCD
3.2 W
Operating
temperature
0 °C to 40 °C (32 °F to 104
°F)
Storage
temperature
-20 °C to + 60 °C (-4 °F to +
140 °F)
Dimensions
(approx.)
54.7 Ч 90 Ч 111.7 mm (2 1/4 Ч
3 5/8 Ч 4 1/2 in.) (w/h/d)
Mass (approx.) DCR-HC32:
400 g (14 oz) main unit only
460 g (1 lb) including the
NP-FP30 rechargeable battery
pack and DVM60 cassette.
DCR-HC42:
410 g (14 oz) main unit only
470 g (1 lb) including the
NP-FP50 rechargeable battery
pack and DVM60 cassette.
Supplied
accessories
See page 9.
Handycam Station DCRA-C121
Audio/Video
input/output
10-pin connector
Input/output auto switch
Video signal: 1 Vp-p, 75 Ω
(ohms), unbalanced
Luminance signal: 1 Vp-p,
75 Ω (ohms), unbalanced
Chrominance signal:
0.286 Vp-p, 75 Ω (ohms),
unbalanced
Audio signal: 327 mV (at
output impedance more than
47 k Ω (kilohms)), Input
impedance more than 47 k Ω
(kilohms), Output impedance
with less than 2.2 k Ω
(kilohms)
USB jack mini-B
DV input/output 4-pin connector
