User's Guide

Page 7

38DHB0002UKDS – Issue 2 (09/01/2002)

Remote Access Module 4

3. Attaching the Mounting Brackets

1. Looking at the base of the IND-RAM4 unit, there are four fixing

screws (beneath the four stick-on pads).

Note:

Do not remove all of these screws at the same time.

2. Remove two of the pads on one side only, undo and remove the

fixing screws. Use two of the longer supplied screws to attach one of
the mounting brackets (such that the slotted central wall fixing holes
are seen from outside the unit); see the illustration on page 5.

3. Repeat step 2 for the other side of the unit for the remaining

mounting bracket.
