Sony PCG-R505TL User Manual
Page 83
Connecting an External Display
83
3
Plug the audio cable into the green Headphone connector on the right side of
the notebook.
Using the Docking Station
1
Locate the
monitor connector on the rear panel of the docking station.
2
Plug the optional monitor adapter into the monitor connector.
3
Plug the audio cable into the green Headphone connector on the right side of
the notebook.
Connecting projector
Projector
Power cord
RGB signal cable
To Headphone
Audio cable
connector
