Caution
Provide an ample amount of space
around the display
• When you use the display, make sure there is more
space around the display than that shown in the
figure below. This will allow for proper ventilation.
• The ambient temperature must be 0 °C to +35 °C
(32 °F to 95 °F).
• Use the SU-P32C display stand (not supplied) as a
stand.
• Regarding installation of hardware such as brackets,
screws, and bolts, we cannot specify what to use
because actual installation is up to the authorized
local dealers. For installation, consult with qualified
Sony personnel.
When using the stand (not supplied)
Front
20 (7
7
/
8
)
10
(4)
10
(4)
ON
ST
ANDBY
Side
7 (2
3
/
4
)
INPUT
1
RGB /
YUV
AUDIO
INPUT
2
CONTROL
S
REMOTE
RGB /
YUV
AUDIO
IN
OUT
COMPOSITE
IN
OUT
Y/C IN
AUDIO IN
VIDEO
Units: cm (inches)
Caution
2.5 (
31
/
32
)
When mounting the display horizontally
Front
25 (9
7
/
8
)
25 (9
7
/
8
)
10
(4)
10
(4)
Side
INPUT
1
RGB /
YUV
AUDIO
INPUT
2
CONTROL
S
REMOTE
RGB /
YUV
AUDIO
IN
OUT
COMPOSITE
IN
OUT
Y/C IN
AUDIO IN
VIDEO
2.5 (
31
/
32
)
Units: cm (inches)
When mounting the display vertically
Front
10 (4)
25
(9
7
/
8
)
20
(7
7
/
8
)
20 (7
7
/
8
)
Side
Units: cm (inches)
Make sure that
the
1
(standby)
switch is at the
bottom.
