INTRODUCTION
W e l com e to th e e xtraordinary w o rl d of Al te c Lansing h igh fide l ity sound.
Th e 4100 is an am pl ifie d m u l tim e dia s ound spe ak e r s ys te m de l ive ring cutting
edge design and te ch nol ogy. Th i s s y s te m is ide al l y suite d to com pute r
Gam ing, ye t w ith a w e l l -rounde d fe ature - s e t de s igne d to provide o p tim al
us age w ith dive rs e audio source s a n d for a wide varie ty of appl ications:
pe rs onal audio de vice s s u c h a s M P 3 p l aye rs , DVD pl aye rs , CD pl aye rs ,
s te re o VCR's and casse tte p l aye rs , pe rsonal com p u te r s ys te m s and various
oth e r vide o/audio source s .
Th e Sate l l ite s ' s l im profil e and tiny footprint fre e up val uabl e de s k top/tabl e top
space , providing an unobtrus ive ye t p o w e rful addition to your m ul tim e dia
configurations.
FEATURE HIGHLIGHTS
• 140 W atts of total s ys te m p o w e r.
• 5 pie ce gaming/m u l tim e dia s pe ak e r s ys te m
• Front and Re ar Inputs for com pute r gam ing.
• 2 audio Inputs (Front & Auxil iary) to al l ow mixing of audio s ignal s fro m tw o
audio source s .
• 2 Modes: Gaming, Ste re o x2.
• 4 Sate l l ite s pe ak e rs: 2 Front Sate l l ite s p e a k e rs and 2 Re a r Sate l l ite
s pe ak e rs e a ch de s i g n e d w i th two 1" (28m m ) s tate of th e art Ne odym ium
m icro drive rs
• A Subwoofe r de s i g n e d w i th two 5.25" (133 m m ) drive rs for e xte nde d l ow
fre q ue ncy re s ponse.
• Separate Subwoofe r vol um e control for fine - tuning syste m bal ance and
ove ral l s ys te m l ow vol um e /h igh vol um e pe rform ance .
• Separate w ire d S y s te m Control l e r unit al l o w s o p tim um s p e a k e r pl ace m e n t
w i th out worrying about control acce s s .
• A pate nte d control circuit autom a tical l y boosts b a s s a t l o w vol um e to
m aintain musical sound "re al i s m ".
• Cutting e dge , s p a c e - s a ving de s i g n .
• A h e adph one jack i s l ocate d on th e Syste m Control l e r unit.
• AAC1 Y-Adapte r incl ude d for e asy conne ction to gam ing cons ol e s .
Th e Subwoofe r is not m agne tical l y s h i e l de d and sh oul d not b e p l ace d in cl o s e
proxim ity to a com pute r m onitor, te l e vision, or com pute r h ard drive .
IMPORTANT
If you e xpe rience any difficul ti e s w i th your s p e a k e r s y s te m , ch e ck th e
Troubl e s h ooting section of th is Guide. Th e ans w e rs to m o s t s e tup and
pe rform ance q ue s tions can be found th e re . If you cannot find th e inform a tion
you ne e d, pl e as e cal l our cus tom e r s e rvice te am for as s i s tance b e fore
re turning th e s pe ak e rs to
your re tail e r unde r th e ir re turn pol icy. W e 're avail abl e 7 days a wee k for your
conve nie nce , (Unite d State s , Easte rn Standard Tim e ):
Monday to Friday: 8:00 a.m. to 12:00 m idnigh t
Saturday & Sunday:9:00 a.m. to 5:00 p.m .
1-800-ALTEC-88 (1-800-258-3288)
CONNECTIONS
Sys te m s e tup configurations to ach i e ve Gam ing Mode and Ste re o x2 Mode
Various conne ction s c h e m e s from your audio source de vice to th e 4100 are
avail abl e . Based on th e fe a ture s of your audio s ource , your s e l e ction of one
of th e s e s ch e m e s w i l l de te rm ine th e ope rational m ode o f your s y s te m .
Do not ins e rt th e p o w e r pl ug into an AC outl e t until al l conne ctions are m ade .
Turn off th e audio source de vice b e fore conne cting its output(s) to th e 4100
Input(s ).
Color Coding: Notice th at th e Input jack s on th e s ubwoofe r are col or
code d to pre ve nt e rrors . Th e pl ugs th at are i n s e rte d into th e s e jack s h ave
m atch ing col ors. As an exampl e , th e Le ft Front Sate l l ite s pe ak e r h as a brown
conne cting pl ug. Th e pl u g i s i n s e rted into th e Le ft Front jack w ith th e brown
col or s trip mark ing. Al l oth e r conne ctions a re m a d e i n th e s am e w ay.
To ins ure firs t-ti m e o p e ration as e xpe cte d , pl e a s e fol l ow th e s e tup s e q u e n ce
be l ow care ful l y in th e orde r indicate d
Gaming setup:
1. Conne ct th e orange pl ug from th e RIGH T FRONT Sate l l ite i n to th e jack
m ark e d RIGH T FRONT on th e Subwoofe r; re pe at th is proce dure for th e LEFT
FRONT Sate l l ite , conne cting th e brown pl ug from th e LEFT FRONT Sate l l ite
to th e jack m ark e d LEFT FRONT on th e Subwoofe r.
2. Conne ct th e purpl e pl ug from th e RIGH T REAR Sate l l ite into th e jack
m ark e d RIGH T REAR on th e Subwoofe r; re pe a t th i s p roce dure for th e LEFT
REAR Sate l l ite , conne cting th e gol d pl ug from th e LEFT REAR Sate l l ite to th e
jack m a rk e d LE FT REAR on th e Subwoofe r.
3. Conne ct th e gray DIN pl ug fro m th e Sys te m Control l e r unit into th e DIN
jack m a rk e d CONTROLLER on th e Subwoofe r. Note th at th e DIN pl ug h as
an arrow . Th e arrow s h oul d be face up for corre ct ins e rtion into th e DIN jack
on th e Subwoofe r.
4. Sh ut th e com pute r s y s te m down using th e m anufacture r's re com m e nde d
proce d u re s .
5. Th e 4100 provide s tw o Inputs l abe l e d FRONT and REAR, l ocate d on th e
Subwoofe r. Com p u te r gam ing s ound cards h ave at l e a s t 2 outputs . M o s t
ofte n, th e outputs w i l l be m a rk e d as front output, and re ar output. Som e
s l igh tl y diffe re nt te rminol ogy m ay be u s e d . H o w e ve r, th e s ound card
instructions wil l provide i n form a tion so th at you can de te rm ine w h at outputs to
u s e w i th a tw o Input s p e a k e r s ys te m . M a k e th e conne ctions using th e two
6.5 ft. (5 m ) gre e n and bl ack cabl e s w i th m atch ing 3.5 m m s te re o pl ugs on
e ach e nd. Th e s e cabl e s a re incl ude d w i th th e 4100 syste m .
6. Conne ct th e p o w e r cord (at back of Subwoofe r) to an AC W al l s o c k e t.
7. Th e unit is now re ady to ope rate . Turn on th e audio source de vice .
Note: Al w a y s turn on your audio s ource de vice be fore turning on your Al te c
Lansing 4100 Speak e r Syste m . If you turn on th e s p e ak e r s ys te m b e fore
turning on th e audio source , you wil l h e ar a l oud POP s ound wh e n th e audio
de vice i s turne d on.
8. Turn on th e Al te c Lansing 4100 Speaker Sys te m . S e e U S E O F
CONTROLS b e l ow.
