• Wait for the answer
• Analyse the received answer: 3 characters plus .
<ACK> <CR> Writing process was successful
<NAK> <CR> Writing process was not successful.
<NOT> <CR> The response of the transponder was not readable.
The result of the writing process may also seen at the LED’s.
• LED L2 lit, if there was a successful write
• LED L3 lit, if there was no successful write.
Example
WD 20 < 0 1 2 7 A C D F > <CR> Write to block 20
Allowed Values (block numbers of the transponder IC):
ALGO 9 (1kBit Memory) 3 .... 31
ALGO 6 (2kBit Memory) 16 ... 63
