23
GB
Specifications
LCD panel Panel type: a-Si TFT Active Matrix
Picture size: 23.0 inch
Input signal format RGB operating frequency*
Horizontal:
28–92 kHz (analog RGB)
28–75 kHz (digital RGB)
Vertical:
48–85 Hz (analog RGB)
60 Hz (digital RGB)
Resolution Horizontal: Max.1920 dots
Vertical: Max.1200 lines
Input signal levels Analog RGB video signal:
0.7 Vp-p, 75
Ω
, positive
SYNC signal:
TTL level, 2.2 k
Ω
,
positive or negative
(Separate horizontal and vertical,
or composite sync)
0.3 Vp-p, 75
Ω
, negative
(Sync on green)
Digital RGB (DVI) signal:
TMDS (Single link)
Power requirements 100–240 V, 50–60 Hz,
Max. 1.0 A
Power consumption Max. 80 W
Operating temperature 5–35 ° C
Dimensions (width/height/depth)
Display (upright):
Approx. 566
Ч
446
Ч
251 mm
(22
3
/ 8
Ч
17
5
/ 8
Ч
10 inches)
(with stand)
Approx. 566
Ч
380
Ч
114 mm
(22
3
/ 8
Ч
15
Ч
4
1
/ 2 inches)
(without stand)
Mass Approx. 12.7 kg (27 lb 16 oz)
(with stand)
Approx. 10.2 kg (22 lb 8 oz)
(without stand)
Plug & Play DDC2B
Accessories See page 7.
* Recommended horizontal and vertical timing condition
• Horizontal sync width duty should be more than 4.8% of total
horizontal time or 0.8 µs, whichever is larger.
• Horizontal blanking width should be more than 2.5 µs.
• Vertical blanking width should be more than 450 µs.
Design and specifications are subject to change without notice.
