14
Fine tuning the color temperature
The setting is stored in memory for each video input connector,
respectively.
1
Press the MENU button.
The main menu appears on the screen.
2
Press the
M
/
m
buttons to select
(PICTURE
ADJUSTMENT) and press the OK button.
The PICTURE ADJUSTMENT menu appears on the screen.
3
Press the
M
/
m
buttons to select “Color” and press
the OK button.
The options are displayed on the popup menu.
4
Press the
M
/
m
buttons to select “Adjust” and press
the OK button.
The fine tuning menu for color temperature appears on the
screen.
5
Press the
M
/
m
buttons to select R (Red) or B (Blue)
and press the OK button. Then press the
M
/
m
buttons to adjust the color temperature and press
the OK button.
Since this adjustment changes the color temperature by
increasing or decreasing the R and B components with respect
to G (green), the G component is fixed.
6
Press the
M
/
m
buttons to select
, then press the
OK button.
The new color setting is stored in memory and automatically
recalled whenever “User” is selected.
The PICTURE ADJUSTMENT menu appears on the screen.
x
Selecting the Gamma
You can associate the picture’s color shade on the screen with the
picture’s original color shade.
1
Press the MENU button.
The main menu appears on the screen.
2
Press the
M
/
m
buttons to select
(PICTURE
ADJUSTMENT) and press the OK button.
The PICTURE ADJUSTMENT menu appears on the screen.
3
Press the
M
/
m
buttons to select “Gamma” and press
the OK button.
The options are displayed on the popup menu.
4
Press the
M
/
m
buttons to select the desired mode.
x
Selecting the Smoothing
If the picture displayed at the “Full2” or “Full1” mode of “Zoom”
is not smooth, use the picture smoothing function.
1
Press the MENU button.
The main menu appears on the screen.
2
Press the
M
/
m
buttons to select
(PICTURE
ADJUSTMENT) and press the OK button.
The PICTURE ADJUSTMENT menu appears on the screen.
3
Press the
M
/
m
buttons to select “Smoothing” and
press the OK button.
The options are displayed on the popup menu.
4
Press the
M
/
m
buttons to select the desired mode.
The smoothing effect becomes stronger in the order of
“Text”
t“Standard”t“Graphics.”
•
Text:
To make the characters appear clear and sharp.
(This mode is suited for text-based applications.)
•
Standard (The default setting):
Standard smoothing
effect.
•
Graphics:
To make the pictures appear clean. (This mode
is suited for CD-ROM software for photo images or
illustrations.)
Notes
• When you set “Zoom” on the OPTION menu to “Real,” “Smoothing”
is not available.
• 1920
×
1200 resolution signals are shown only in the “Real” mode and
“Smoothing” is not possible.
R :
110
G :
128
B :
140
Set
Exit
MENU
Select
OK
1: HD15
PICTURE ADJUSTMENT
Backlight :
100
Contrast :
50
Brightness :
50
Color :
9300K
Gamma :
Gamma1
Smoothing :
Gamma2
Gamma3
1920
×
1200/60 Hz
Set
Exit
MENU
Select
OK
1: HD15
PICTURE ADJUSTMENT
Backlight :
100
Contrast :
50
Brightness :
50
Color :
9300K
Gamma :
Gamma2
Smoothing :
Text
Standard
Graphics
1920
×
1200/60 Hz
