Sony PCG-R505GL - Manual (Page 148)

VAIO Computer Quick Start
148
5 Turn the computer over so you are looking at the keyboard, and place your
fingers behind the last row of keys.
6 Gently lift the keyboard up and turn it over the touch pad. Do not detach the
cable when lifting the keyboard.
7 Touch a metal object (such as the connector panel on the back of your
computer) to discharge static electricity.
8 Remove the memory module by pulling out the tabs (see arrows No. 1), and
pulling out the module in the direction of arrow No. 2. See “To install a
memory module” for information about installing a memory module.
Removing the Bottom Screws
Lifting the Keyboard
Screws
Cable
Place your
fingers behind
the last row
of keys
Memory slot
