9.9 T
ypical r
echarge time and run time versus load
9.9.2 2000V
A models
Number Of
1
2
3
4
5
6
7
8
9
10
10 plus
adder
* recharge to 90% of capacity
Battery Packs
subsequent discharge into
Recharge
Time*
2.2 hr
4.5 hr
6.8 hr
9.2 hr
11.8 hr
14.2 hr
16.5 hr
19.2 hr
21.9 hr
24.0 hr
+ 2.4 hr
50% of rated load
Computer Load
Typical computer load
(Volt-Amps)
(p.f. typically 0.6 to 0.7)
200 VA
2.9 hr
6.2 hr
9.8 hr
14.4 hr
19.2 hr
24.1 hr
28.8 hr
32.9 hr
37.0 hr
41.1 hr
+ 4.1 hr
IBM PS/2 55sx w/ VGA monitor
250 VA
2.5 hr
5.3 hr
8.4 hr
11.8 hr
16.1 hr
20.3 hr
24.6 hr
28.6 hr
32.2 hr
35.8 hr
+ 3.6 hr
Compaq 386/25e w/ VGA monitor
300 VA
2.2 hr
4.7 hr
7.3 hr
10.1 hr
13.6 hr
17.4 hr
21.2 hr
24.9 hr
28.5 hr
31.7 hr
+ 3.2 hr
Compaq 386/33 w/ VGA monitor
350 VA
1.9 hr
4.2 hr
6.5 hr
8.9 hr
11.7 hr
15.0 hr
18.4 hr
21.8 hr
25.1 hr
28.3 hr
+ 3.2 hr
IBM PS/2 95 file server
400 VA
1.7 hr
3.7 hr
5.8 hr
8.0 hr
10.2 hr
13.1 hr
16.1 hr
19.2 hr
22.2 hr
25.3 hr
+ 3.1 hr
Compaq 386/33 w/ 19" monitor
500 VA
1.4 hr
3.1 hr
4.8 hr
6.5 hr
8.4 hr
10.3 hr
12.6 hr
15.2 hr
17.7 hr
20.3 hr
+ 2.6 hr
Compaq Systempro server
600 VA
1.1 hr
2.6 hr
4.0 hr
5.5 hr
7.1 hr
8.7 hr
10.2 hr
12.3 hr
14.5 hr
16.6 hr
+ 2.1 hr
(2) Compaq 386/33 w/ monitors
700 VA
0.9 hr
2.2 hr
3.5 hr
4.7 hr
6.0 hr
7.4 hr
8.8 hr
10.2 hr
11.9 hr
13.8 hr
+ 1.9 hr
(2) IBM PS/2 95 file servers
800 VA
0.8 hr
1.9 hr
3.0 hr
4.2 hr
5.3 hr
6.5 hr
7.7 hr
8.9 hr
10.1 hr
11.6 hr
+ 1.5 hr
IBM AS/400 D20 minicomputer
900 VA
0.7 hr
1.7 hr
2.7 hr
3.7 hr
4.7 hr
5.7 hr
6.8 hr
7.9 hr
9.0 hr
10.1 hr
+ 1.1 hr
DEC MicroVax
1000 VA
0.6 hr
1.5 hr
2.4 hr
3.3 hr
4.2 hr
5.1 hr
6.0 hr
7.0 hr
8.0 hr
9.0 hr
+ 1.0 hr
(2) Compaq Systempro servers
1200 VA
0.5 hr
1.2 hr
1.9 hr
2.7 hr
3.4 hr
4.2 hr
4.9 hr
5.7 hr
6.5 hr
7.3 hr
+ 0.8 hr
(4) Compaq 386/33 w/ VGA mon.
1600 VA
0.3 hr
0.8 hr
1.3 hr
1.9 hr
2.4 hr
3.0 hr
3.5 hr
4.1 hr
4.7 hr
5.2 hr
+ 0.6 hr
(8) IBM PS/2 55sx w/ VGA mon.
2000 VA
0.2 hr
0.6 hr
1.0 hr
1.4 hr
1.8 hr
2.3 hr
2.7 hr
3.1 hr
3.6 hr
4.0 hr
+ 0.5 hr
(4) Compaq Systempro servers
Note:
Run times are typical at 25°C (77°F). Add the values given in the "10 plus adder" column to the values given in
the "10" column for each Battery pack installed above a total of 10.
Example:
When 13 Battery packs are installed, the
recharge time is typically less than 24 + 2.4 + 2.4 + 2.4 = 31.2 hrs. The run time for this system at full load is typically greater than 4.0 + 0.5 + 0.5 + 0.5 = 5.5 hrs.
