212
Specifications
General
Power requirements
7.2 V (battery pack)
8.4 V (AC Adaptor)
Average power consumption
(when using the battery pack)
DCR-TRV19/TRV22:
3.3 W 1)
2.5 W 2)
DCR-TRV33:
4.1 W 1)
3.3 W 2)
1) During camera recording using
LCD
2) Viewfinder
Operating temperature
0°C to 40°C (32°F to 104°F)
Storage temperature
–20°C to + 60°C
(–4°F to + 140°F)
Dimensions (approx.)
71
Ч
90
Ч
112 mm
(2 7/8
Ч
3 5/8
Ч
4 1/2 in.) (w/h/d)
Mass (approx.)
Main unit only
DCR-TRV19:
520 g (1 lb 2 oz)
DCR-TRV22:
530 g (1 lb 2 oz)
DCR-TRV33:
540 g (1 lb 2 oz)
Including the rechargeable battery
pack NP-FM30, cassette DVM60
and lens cap
DCR-TRV19:
610 g (1 lb 5 oz)
DCR-TRV22:
620 g (1 lb 5 oz)
DCR-TRV33:
630 g (1 lb 5 oz)
Supplied accessories
See page 15.
AC Adaptor
AC-L15A/L15B
Power requirements
100 – 240 V AC, 50/60 Hz
Current consumption
0.35 – 0.18 A
Power consumption
18 W
Output voltage
DC OUT: 8.4 V, 1.5 A
Operating temperature
0°C to 40°C (32°F to 104°F)
Storage temperature
–20°C to + 60°C
(–4°F to + 140°F)
Dimensions (approx.)
56
Ч
31
Ч
100 mm
(2 1/4
Ч
1 1/4
Ч
4 in.) (w/h/d)
excluding projecting parts
Mass (approx.)
190 g (6.7 oz)
excluding power cord
Rechargeable
battery pack
NP-FM30
Maximum output voltage
DC 8.4 V
Output voltage
DC 7.2 V
Capacity
5.0 Wh (700 mAh)
Dimensions (approx.)
38.2
Ч
20.5
Ч
55.6 mm
(1 9/16
Ч
13/16
Ч
2 1/4 in.)
(w/h/d)
Mass (approx.)
65 g (2.3 oz)
Operating temperature
0°C to 40°C (32°F to 104°F)
Type
Lithium ion
“Memory Stick”
(DCR-TRV22/TRV33
only)
Memory
Flash memory
8MB: MSA-8A
Operating voltage
2.7 – 3.6 V
Power consumption
Approx. 45 mA during operation
mode
Approx. 130 µA during tape
recording standby
Dimensions (approx.)
50
Ч
2.8
Ч
21.5 mm
(2
Ч
1/8
Ч
7/8 in.) (w/h/d)
Mass (approx.)
4 g (0.14 oz)
Design and specifications are
subject to change without notice.
