5 - 2 4 5 - 2 4 5 - 2 4 5 - 2 4 5 - 2 4 C h a p t e r 5 : S o f t w a r e s u p p o r t C h a p t e r 5 : S o f t w a r e s u p p o r t C h a p t e r 5 : S o f t w a r e s u p p o r t C h a p t e r 5 : S o f t w a r e s u p p o r t C h a p t e r 5 : S o f t w a r e s u p p o r t
5.4.1 5.4.1 5.4.1 5.4.1 5.4.1 Installing hard disks Installing hard disks Installing hard disks Installing hard disks Installing hard disks
The motherboard supports Ultra DMA /133/100/66 and Serial ATA hard
disk drives. For optimal performance, install identical drives of the same
model and capacity when creating a disk array.
Installing Parallel ATA hard disks Installing Parallel ATA hard disks Installing Parallel ATA hard disks Installing Parallel ATA hard disks Installing Parallel ATA hard disks
To install IDE hard disks for a RAID configuration:
1. Set the jumpers of each hard disk as Master/Master or Slave/Slave.
2. Install the hard disks into the drive bays.
3. Connect the HDD signal cables.
4. Connect a 4-pin power cable to the power connector on each drive.
Installing Serial ATA (SATA) hard disks Installing Serial ATA (SATA) hard disks Installing Serial ATA (SATA) hard disks Installing Serial ATA (SATA) hard disks Installing Serial ATA (SATA) hard disks
To install the SATA hard disks for a RAID configuration:
1. Install the SATA hard disks into the drive bays.
2. Connect the SATA signal cables.
3. Connect a SATA power cable to the power connector on each drive.
Refer to the RAID controllers user manual in the motherboard support
CD for detailed information on RAID configurations. See section “5.2.4
Manuals menu”.
