S109
K56flex and V.90 Selection (default 1)
Use this register to disable 56K connections or to choose between K56flex and V.90
protocols. The default setting (S109=1) will attempt K56flex first, then V.90, and
then V.34 depending upon the central site modem being called and your phone line
conditions. (see the next page for listing.)
S109 = 0
Disable all 56K connections
S109 = 1
K56flex first, then V.90 (default)
S109 = 2
V.90 only. K56flex disabled
Table 2. The Result Code Summary
Result Code
Description
OK
Command executed
CONNECT
Modem connected to line
RING
A ring signal has been detected
NO CARRIER
Modem lost carrier signal, or does not detect carrier signal, or
does not detect answer tone
ERROR
Iinvalid command
CONNECT 1200 EC*
Connection at 1200 bits/s
NO DIALTONE
No dial tone detected
BUSY
Busy signal detected
NO ANSWER8
No quiet answer
CONNECT 2400 EC*
Connection at 2400 bits/s
CONNECT 4800 EC*
Connection at 4800 bits/s
CONNECT 9600 EC*
Connection at 9600 bits/s
CONNECT 14400 EC*
Connection at 14400 bits/s
CONNECT 19200 EC*
Connection at 19200 bits/s
CONNECT 7200 EC*
Connection at 7200 bits/s
CONNECT 12000 EC*
Connection at 12000 bits/s
CONNECT 16800 EC*
Connection at 16800 bits/s
CONNECT 300 EC*
Connection at 300 bits/s
CONNECT 21600 EC*
Connection at 21600 bits/s
CONNECT 24000 EC*
Connection at 24000 bits/s
CONNECT 26400 EC*
Connection at 26400 bits/s
CONNECT 28800 EC*
Connection at 28800 bits/s
CONNECT 31200 EC*
Connection at 31200 bits/s
CONNECT 33600 EC*
Connection at 33600 bits/s
CONNECT 38400 EC*
Connection at 38400 bits/s
CONNECT 57600 EC*
Connection at 57600 bits/s
CONNECT 115200 EC
Connection at 115200 bits/s
DELAYED
Delay is in effect for the dialed number
BLACKLISTED
Dialed number is blacklisted
BLACKLIST FULL
Blacklist is full
CONNECT 32000 EC*
Connection at 32000 bits/s, 56K rate
CONNECT 34000 EC*
Connection at 34000 bits/s, 56K rate
CONNECT 36000 EC*
Connection at 36000 bits/s, 56K rate
CONNECT 38000 EC*
Connection at 38000 bits/s, 56K rate
CONNECT 40000 EC*
Connection at 40000 bits/s, 56K rate
