Quick Reference 134
2
3
1
5
4
A
OPEN/EJECT lever (p. 19)
B Cassette lid (p. 19)
C Grip Belt (p. 4)
D MIC (PLUG IN POWER) jack
REAR (black)/FRONT (red) (p. 27, 98)
This jack works as an input jack for an
external microphone as well as a power-
supply jack for a plug-in-power
microphone. When the external
microphone is connected, it takes
precedence.
E MIC jack cover
3
2
1
4
5
A Tripod receptacle
Make sure that the length of the tripod
screw is less than 5.5 mm (7/32 inch).
Otherwise, you cannot attach the tripod
securely, and the screw may damage your
camcorder.
B “Memory Stick Duo” cover (p. 20)
C Hooks for shoulder strap
D Access lamp (p. 20, 122)
E “Memory Stick Duo” slot (p. 20)
To attaching the shoulder strap
Attach the shoulder strap supplied with your
camcorder to the hooks for the shoulder strap.
