On the Docking Station
Your notebook may come with a PCGA-DSD5 or PCGA-DSM5 docking station,
depending on the model you purchased. Both Sony docking stations provide you
with the following features:
❑ A floppy disk drive.
❑ An optical drive.
❑ A back panel that enables you to connect additional peripherals to your
notebook, as shown below.
Back Panel
1 USB ports 5 Ethernet port
(10BaseT/100Base-TX)
2 Monitor port 6 i.LINK®
*
(IEEE 1394)
S400 port
3 Serial port 7 Printer port
4 DC In port
7 6 5 4
1 2 3
