4
Chapiter 2
Using I-Fly Wireless Access Point
2.1 Cautions for using the I-Fly Wireless Access Point
Do not place the AP under high humidity and high temperature.
Do not use the same power source for AP with other equipment.
Do not open or repair the case yourself. If the AP is too hot, turn off the power
immediately and have a qualified serviceman repair it.
Place the AP on a stable surface.
Only use the power adapter that comes with the package, Using a power supply with
a different voltage rating than the one included will cause damage and void the
warranty for this product.
2.2 The Front LEDs
LED MEANING
1 POWER
ON=Indicates proper connection to power supply.
OFF= The unit is not receiving power
2 LAN
ON= Indicates connection is established.
BLINKING= Data transmissions
OFF= No LAN connections
3 WLAN
ON= Link is established
BLINKING= Packet transmit or receive activity
OFF= No Link activity
2.3 The Rear Ports
PORT MEANING
1 POWER (Jack) Receptor for the Power Adapter
2 LAN Auto MDI/MDIX LAN ports automatically
sense the cable type when connecting to
Ethernet-enabled computers.
3 RESET After the device has turned on, press it (10s) to
reset the device or restore to factory default
settings.
