Using the TX-CTB
6 TX-CTB Classroom Transmitter and Barcode Reader
Computer
To control the CD-I mouse, use the buttons labeled in yellow. Then, press one of the eight outer
number buttons (1 – 4 or 6 – 9). For information on the Speed and how to activate functions refer to
the CD-I Player subsection.
Slides
To control video slide projectors and still video players, use the following buttons::
Barcode Reader
To read a barcode:
1. Press READ. The LED turns green.
2. Hold the TX-CTB so the reader is perpendicular to the barcode.
3. Swipe the reader over the barcode until the TX-CTB beeps once. Follow these guidelines:
! If it does not beep, do not lift the reader from the page; swipe the reader over the barcode
in the other direction.
! It may take more than one pass, or it may take a pass in theother direction to read the
barcode.
4. After the TX-CTB beeps once, point it at the AXB-TM5.
5. Press SEND. The LED turns yellow when the TX-CTB transmits the data.
After five seconds of inactivity, the TX-CTB beeps twice and returns to normal IR operation.
PLAY (slides on)
STOP (slides off)
PAUSE (still video standby)
FFWD (zoom in)
REV (zoom out)
FWD (forward)
REV (reverse)
