Chapter 5. OSD Operation
105
For example, the station ID of the first KM0432 or KM0216 in the
daisy chain is 2.
2 - 1 = 1
The KM0432 or KM0216’s position in the daisy chain is 1.
The table below lists the KM0432 or KM0216’s station ID and its position
in the daisy chain.
3. The port number on the KM0432 or KM0216
For example, a computer attached to Port 18 of a KM0432 or KM0216, which
is in Position 7 in the daisy chain (Station ID 8), which in turn is daisy-chained
from the first-level KM0832, would have a port ID of: 1-7-18.
Station ID
Position in the Daisy
Chain
2 1
3 2
4 3
5 4
6 5
7 6
8 7
