ComProtect ® Building Entrance Terminals (BET )
Enclosed, Integrated Protection with LSA-PLUS ® Series 2 Blocks
2 w w w . a d c . c o m • + 1 - 9 5 2 - 9 3 8 - 8 0 8 0 • 1 - 8 0 0 - 3 6 6 - 3 8 9 1
Specifications
ELECTRICAL CHARACTERISTICS:
BET Dielectric Withstand
4000 VDC
CONSTRUCTION CHARACTERISTICS:
MECHANICAL CHARACTERISTICS:
LSA-PLUS Series 2 Subscriber Interface:
Contact Resistance
< 1 m Ω
Insulation Resistance ≥ 5 x 10 4 MΩ
Contact Material Copper Alloy
Contact Plating Silver
Number of Test Cord Insertions > 750
IDC Reterminations 200
Wire Diameter Range for Solid and Stranded Copper Conductors:
Two Conductors per Contact (same diameter)
22-26 AWG 0.65 to 0.40 mm
(0.026" to 0.016")
One Conductor per Contact 20-26 AWG 0.90 to 0.40 mm
(0.035" to 0.016")
Wire Insulation Diameter Range (PE,PVC) 0.68 mm to 1.60 mm
(0.027" to 0.063")
ENVIRONMENTAL CHARACTERISTICS:
Dimensions:
Indoor/Outdoor
25-pair and
50-pair
252.22mm x 314.96mm x 165.10mm
9.93"H x 12.40"W x 6.50"D
100-pair
377.19mm x 314.96mm x 161.10mm
14.85"H x 12.40"W x 6.50"D
Operating Temperature:
Indoor/Outdoor -40 ˚ to 80 ˚ C (-40 ˚ to 176 ˚ F)
