Page 9
- 9 -
Part Numbers for Ordering (CYLINDERS)
Part
TX2
TX4
TX8
TX16
TX32
1
HOUSING
TX-2-C01
TX-4-C01
TX-8-C01
TX-16-C01
TX-32-C01
PISTON ROD ASSEMBLY
TX-2-C03
TX-4-C03
TX-8-C03
TX-16-C03
TX-32-C03
2
PISTON ROD
TX-2-C03-1
N/A
N/A
TX-16-C03-1 TX-32-C03-1
3
PISTON CAP
N/A
N/A
N/A
TX-16-C03-2 TX-32-C03-2
VALVE BALL
N/A
N/A
N/A
TX-16-C03-3 TX-32-C03-3
VALVE SPRING
N/A
N/A
N/A
TX-16-C03-4 TX-32-C03-4
VALVE HOLLOW LOCK
N/A
N/A
N/A
TX-16-C03-5 TX-32-C03-5
4
PISTON SEAL PLATE
TX-2-C05
TX-4-C05
TX-8-C05
N/A
N/A
5
SEAL RING
TX-2-C07
TX-4-C07
TX-8-C07
N/A
N/A
6
SLIDER
TX-2-C09
TX-4-C09
TX-8-X09
TX-16-C09
TX-32-C09
7
END CAP
TX-2-C11
TX-4-C11
TX-8-C11
TX-16-C11
TX-32-C11
8
RETAINING RING
TX-2-C13
TX-4-C13
TX-8-C13
N/A
N/A
9
LINK PIN
TX-2-C15
TX-4-C15
TX-8-C15
TX-16-C15
TX-32-C15
10
END COVER
TX-2-C17
TX-4-C17
N/A
N/A
N/A
11
RETAINING SCREWS
TX-2-C21
TX-4-C21
TX-8-C21
N/A
N/A
12
END COVER SCREWS
TX-2-C23
TX-4-C23
N/A
N/A
N/A
13
BALL PLUNGER
TX-2-C25
TX-4-C25
TX-8-C25
TX-16-C25
TX-32-C25
14
SLIDER PIN
TX-2-C27
TX-4-C27
TX-8-C27
TX-16-C27
TX-32-C27
15
END PLUG SEAL
TX-2-C29
TX-4-C29
TX-8-C29
TX-16-C29
TX-32-C29
16
ROD SEAL
TX-2-C31
TX-4-C31
TX-8-C31
TX-16-C31
TX-32-C31
17
PISTON O-RING
TX-2-C33
TX-4-C33
TX-8-C33
TX-16-C33
TX-32-C33
18
SWIVEL SET
N/A
STX-4M-4M STX-4M-4M STX-4M-4M
STX-4M-4M
18
SWIVEL SET
STX-4M-8M
N/A
N/A
N/A
N/A
19
COUPLER ASSEMBLY
HC-S100
HC-S100
HC-S100
HC-S100
HC-S100
20
SEAL INSERTION TOOL
TX-2-ST
TX-4-ST
TX-8-ST
N/A
N/A
21
END PLUG WRENCH
N/A
N/A
N/A
TX-16-EPW
TX-32-EPW
