- 4 -
TX Series Torque Conversion Chart
Bar/N.M.
TX-2 TX-4 TX-8 TX-16 TX-32
Hex 3/4" to 1-13/16" 1-7/8" to 2-3/8" All Hex Sizes All Hex Sizes 2-5/8" to 3-15/16" 4" to 4-5/8" 2-7/16" to 4-5/8" 4-11/16" to 6-1/2"
Sizes 19 to 46MM 47 to 60MM All Hex Sizes All Hex Sizes 65 to 100MM 105 to 115MM 80 to 115MM 115 to 155MM
Bar N.m. N.m. N.m. N.m. N.m. N.m. N.m. N.m.
68 260 285 535 1,125 2,115 2,250 #VALUE! 5,016
82 312 342 644 1,357 2,535 2,700 #VALUE! 6,019
95 365 399 752 1,590 2,955 3,150 #VALUE! 7,022
109 416 455 854 1,822 3,382 3,600 #VALUE! 8,025
122 469 512 962 2,055 3,802 4,051 #VALUE! 9,028
136 522 569 1,071 2,288 4,229 4,501 #VALUE! 10,031
150 572 626 1,179 2,528 4,650 4,951 #VALUE! 11,035
163 625 683 1,288 2,768 5,070 5,401 #VALUE! 12,038
177 678 740 1,389 3,008 5,490 5,851 #VALUE! 13,041
190 728 797 1,498 3,248 5,917 6,301 #VALUE! 14,044
204 784 868 1,606 3,489 6,337 6,751 #VALUE! 15,047
218 832 923 1,715 3,762 6,764 4,826 #VALUE! 16,050
231 885 981 1,823 4,034 7,185 7,651 #VALUE! 17,053
245 937 1,038 1,925 4,307 7,605 8,101 #VALUE! 18,057
258 990 1,097 2,033 4,579 8,032 8,551 #VALUE! 19,060
272 1,045 1,159 2,142 4,853 8,452 9,015 #VALUE! 20,063
286 1,093 1,212 2,250 5,063 8,879 9,466 #VALUE! 21,066
299 1,145 1,270 2,359 5,275 9,299 9,916 #VALUE! 22,069
313 1,197 1,328 2,460 5,485 9,720 10,368 #VALUE! 23,072
326 1,250 1,385 2,569 5,696 10,147 10,818 #VALUE! 24,075
340 1,307 1,450 2,677 5,908 10,567 11,333 #VALUE! 25,079
354 1,353 1,507 2,786 6,152 10,987 11,786 #VALUE! 26,082
367 1,406 1,566 2,894 6,396 11,414 12,240 #VALUE! 27,085
381 1,457 1,624 2,996 6,640 11,834 12,692 #VALUE! 28,088
394 1,510 1,682 3,104 6,884 12,261 13,147 #VALUE! 29,091
408 1,567 1,742 3,213 7,128 12,682 13,692 #VALUE! 30,094
422 1,613 1,799 3,321 7,334 13,102 14,148 #VALUE! 31,097
435 1,666 1,857 3,430 7,540 13,522 14,604 #VALUE! 32,101
449 1,718 1,914 3,531 7,747 13,949 15,061 #VALUE! 33,104
462 1,769 1,972 3,640 7,953 14,369 15,518 #VALUE! 34,107
476 1,829 2,033 3,748 8,161 14,796 15,888 #VALUE! 35,110
490 1,873 2,089 3,857 8,386 15,217 16,342 #VALUE! 36,113
503 1,926 2,146 3,965 8,611 15,637 16,796 #VALUE! 37,116
517 1,979 2,204 4,067 8,837 16,064 17,250 #VALUE! 38,119
530 2,029 2,262 4,175 9,062 16,484 17,630 #VALUE! 39,123
544 2,090 2,325 4,284 9,289 16,911 18,314 #VALUE! 40,126
558 2,134 2,379 4,392 9,520 17,331 18,772 #VALUE! 41,129
571 2,187 2,437 4,501 9,754 17,752 19,231 #VALUE! 42,132
585 2,238 2,494 4,602 9,985 18,172 19,687 #VALUE! 43,135
598 2,291 2,553 4,711 10,219 18,599 20,146 #VALUE! 44,138
612 2,352 2,615 4,819 10,452 19,019 20,361 #VALUE! 45,141
626 2,394 2,669 4,928 10,701 19,446 20,814 #VALUE! 46,145
639 2,447 2,726 5,029 10,951 19,866 21,267 #VALUE! 47,148
653 2,498 2,784 5,138 11,200 20,287 21,718 #VALUE! 48,151
666 2,551 2,843 5,246 11,449 20,714 22,171 #VALUE! 49,154
680 2,614 2,908 5,355 11,699 21,141 22,503 #VALUE! 50,157
