- 7 -
Part Numbers for Ordering (LINKS)
Part TX2 TX4 TX8 TX16 TX32
1 SIDE PLATE - L TX-2-L01 TX-4-L01 TX-8-L01 TX-16-L01 TX-32-L01
2 SIDE PLATE - R TX-2-L02 TX-4-L02 TX-8-L02 TX-16-L02 TX-32-L02
3 DRIVE PLATE TX-2-L03 TX-4-L03 TX-8-L03 TX-16-L03 TX-32-L03
4 DRIVE PIN TX-2-L05 TX-4-L05 TX-8-L05 TX-16-L05 TX-32-L05
5 DRIVE PIN SPRING TX-2-L07 TX-4-L07 TX-8-L07 TX-16-L07 TX-32-L07
6 RATCHET TX-2-L09 TX-4-L09 TX-8-L09 TX-16-L09 TX-32-L09
7 DRIVE SEGMENT TX-2-L11 TX-4-L11 TX-8-L11 TX-16-L11 TX-32-L11
8 UPPER SPACER TX-2-L13 TX-4-L13 TX-8-L13 TX-16-L13 TX-32-L13
9 MIDDLE SPACER N/A N/A N/A TX-16-L14 TX-32-L14
10 LOWER SPACER TX-2-L15 TX-4-L15 TX-8-L15 TX-16-L15 TX-32-L15
11 LOWER SPACER PIN TX-2-L17 TX-4-L17 TX-8-L17 TX-16-L17 TX-32-L17
12 SLEEVES - SIDEPLATE TX-2-L19 TX-4-L19 TX-8-L19 TX-16-L19 TX-32-L19
13 SHROUD TX-2-L21 TX-4-L21 TX-8-L21 TX-16-L21 TX-32-L21
14 SEGMENT SPRING TX-2-L25 TX-4-L25 TX-8-L25 TX-16-L25 TX-32-L25
15 SCREWS - UPPER SPACER TX-2-L27 TX-4-L27 TX-8-L27 TX-16-L27 TX-32-L27
16 SCREWS - LOWER SPACER TX-2-L29 TX-4-L29 TX-8-L29 TX-16-L29 TX-32-L29
17 SHROUD SCREWS TX-2-L31 TX-4-L31 TX-8-L31 TX-16-L31 TX-32-L31
18 DRIVE PIN SPRING ROLL PIN TX-2-L33 TX-4-L33 TX-8-L33 TX-16-L33 TX-32-L33
19 SPACER ROLL PIN N/A N/A N/A TX-16-35 TX-32-L35
