– 1
Please read and comply with
these original instructions prior
to the initial operation of your appliance and
store them for later use or subsequent own-
ers.
In case of transport damage inform vendor
immediately
1 High pressure hose
2 Hand spray gun
3 Spray lance
4 Oil tank
5 Fuel tank
6 Nozzle
7 Device for manual start
8 Detergent suction hose with filter and
dosing valve
9 Water connection
10 High pressure connection
1 High pressure hose
2 Hand spray gun
3 Spray lance
4 Pressure/ quantity regulation
5 Nozzle
6 Fuel tank
7 Device for manual start
8 Oil tank
9 Connection for water supply with filter
10 High pressure connection
11 Manometer
12 Oil dip (engine)
13 Dosage valve for detergent
14 Detergent suction hose with filter
15 Motor
16 High pressure pump
1 High pressure hose
2 Hand spray gun
3 Spray lance
4 Pressure/ quantity regulation
5 Nozzle
6 Fuel tank
7 Device for manual start
8 Oil filling container
9 Connection for water supply with filter
10 High pressure connection
11 Manometer
12 Battery
13 Start switch
14 Oil dip (engine)
15 Dosage valve for detergent
16 Detergent suction hose with filter
17 Lever for engine stop
18 Motor
19 High pressure pump
– The operating elements for the cleaning
process are yellow.
– The controls for the maintenance and
service are light gray.
Contents
Control elements . . . . . . . . EN . . .1
For Your Safety . . . . . . . . . EN . . .2
Environmental protection . . EN . . .3
Proper use . . . . . . . . . . . . . EN . . .3
Safety Devices . . . . . . . . . . EN . . .3
Start up. . . . . . . . . . . . . . . . EN . . .3
Operation . . . . . . . . . . . . . . EN . . .4
Transport . . . . . . . . . . . . . . EN . . .7
Storage. . . . . . . . . . . . . . . . EN . . .7
Maintenance and care . . . . EN . . .7
Faults . . . . . . . . . . . . . . . . . EN . . .8
Spare parts. . . . . . . . . . . . . EN . . .9
Warranty. . . . . . . . . . . . . . . EN . . .9
EC Declaration of Conformity EN . . .9
Specifications . . . . . . . . . . . EN . .10
Control elements
HD 801 B Cage
HD 1050 B Cage
HD 1050 DE Cage
Colour coding
