Specification
General
STB Type
DVBS Receiver
Main Chipset
ALI M3329C(128 pin)
Mechanical
7E CASE
Func/Interface
FTA,RCA,21~69 RF out
Video Modulator
Independent
TUNER Type
Onboard Design
Demodulator Type
Embed to Main Chip Set
SMPS Type
Separate SMPS
Hardware Features
IR
38KHz
Remoter Type
RA0
Dimension
W
：26.0 cm，D：18.0 cm，H：4.5 cm
Net Weight
1.5 kg
Main Chip Sets
CPU frequency
216MHz
Flash Memory
1PC 16Mbit/2MByte
SDRAM Memory
1PC 4X16Mbit/8Mbyte SDR
Demodulator IC
Building in Main Chip Set
DVBS Tuner
Tuner Type
ZARLINK 10039 ON BOARD
Frequency Range
950
～ 2150MHz
Input Impedance
75Ω
Power and Polarization
Vertical 13VDC;Horizontal 18VDC @ 300mA (max) 22KHz±4KHz(0.6V±0.2V)tone, Overload Protection
Input Level Range
65dBm
～ -25dBm
DVBS Channel Decoder
DVBS Demod standard
DVB-S
（ETS 300 421）
DVBS Demodulation
QPSK
DVBS Symbol Rate
2
～ 45MSPS（Code Rate 1/2）
DVBS Code Rate
1/2
、2/3、3/4、5/6、7/8
TS Demux
Demultiplexer
MPEG2 ISO/IEC 13818-1
Input Bit Rate
Max 100Mbit/s
Video Decode
Video Decode
MPEG2 ISO/IEC 13818-2 MP@ML
Aspect Ratio
4:3
、16:9
Video Resolution
720×576(PAL) 720×480(NTSC)
Audio Decode
Audio Decode
MPEG1,MPEG2 ISO/IEC 13818-3 LAYER I&II
Sampling Frequency
32KHz
、44.1KHz、48KHz
AV Output
Video Bandwidth
5.5MHz(-3dB)
Video Impedance
75Ω
Video Voltage Level
1.0 Vp-p
Audio Freq. Range
20
～15KHz
Audio Impedance
600Ω
Audio Voltage Level
2V rms(5.6Vp-p)
Environment
Input Voltage
AC 100
～240V，50Hz/60Hz
Consumption
Max 20W
Temperature
0
～40℃
Humidity
<95
％
