d) Make sure that the manometers are seated securely on the acetylene and
oxygen pressure regulator. Replace damaged manometers only with original
Rothenberger replacement parts.
e) Safety check valve for oxygen and acetylene to be used in intellectual property
applications.
5) Service
Have your device repaired only by qualified experts and only with original
replacement parts. This ensures the continued safety of the device.
1.3
Special safety instructions
Acetylen gas is highly flammable, colourless, heavier than air, and has a perceptible odour.
Cartridges and acetylene tanks must not be handled by children.
Store the acetylene tanks and oxygen tanks in a well-ventilated area.
Do not smoke when working near the tanks.
Keep the cartridges and oxygen tanks away from ignition sources.
Check the screw joints’ tightness using foaming substances (e.g., soapy water, leak detection
spray).
Close the tank valves during malfunctions and after work.
Do not use the device in a horizontal position. When cartridges lie flat, liquid MAXI gas enters
the gas cartridge valve and the burner nozzle, and that leads to malfunctions.
Acetylene gas transport or do not operate lying. (Acetone leaks out).
2
Technical data
Welding inserts
Welding
insert
Welding
size
Article-
No.
Gas type Oxygen
pressure
Acetylene-
pressure
Sauer-
stoffver-
brauch
Acetylene-
consumpti
on
Size
[mm]
[bar] [bar] [l/h] [l/h]
1
0,5 - 1,0
3.5325
80
80
2
1,0 - 2,0
3.5326
160
160
3
2,0 - 4,0 3.5327 Acetylene
2,5 0,2 315 315
4
4,0 - 6,0
3.5328
500
500
5
6,0 - 9,0
3.5329
800
800
6
9,0 - 14,0
3.5334
1250
1250
RE 17 UNIVERSAL
Triple Gas System
AMS 5/5
RE 17 UNIVERSAL
Triple Gas System
AMS 10/10
RE 17 STANDARD
Triple Gas System
AMS 10/10
Product
number: 3.5400 3.5401 3.5798
Cylinder contents
5 l acetylene /
5 l oxygen /
600 ml Maxigas
10 l acetylene /
10 l oxygen /
600 ml Maxigas
10 l acetylene /
10 l oxygen /
600 ml Maxigas
Welding range:
0.5 to 14 mm
0.5 to 9 mm
Cutting range:
3.0 to 50 mm
3.0 to 25 mm
Welding and cutting:
Acetylene with oxygen
Hard soldering:
Acetylene with oxygen or
MAXIGAS with adapter and torch (accessories)
Operating temperature:
1 250°C
Flame temperature:
3 100°C
