6
SECTION II
SPECIFICATIONS/COMPONENT IDENTIFICATION
A. SPECIFICATIONS
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
IMPORTANT: Steam dryers must be provided with clean, dry, regulated 80 PSI ± 10 PSI
(5.52 bars ± 0.68 bars) air supply.
AMPS
WITHOUT HEAT RECLAIMER
WITH
HEAT RECLAIMER
MAXIMUM CAPACITY (DRY WEIGHT) 55 lbs 25 kg
BASKET (TUMBLER) DIAMETER 37" 94 cm
BASKET (TUMBLER) DEPTH 30" 76.2 cm
BASKET (TUMBLER) VOLUME 18.67 cu. ft. 0.528 cu. m.
MOTOR (HORSEPOWER) 3/4 HP 0.56 kw
DOOR OPENING 31-3/8" 79.7 cm
APPROX. WEIGHT (UNCRATED) 585 lbs 265 kg 630 lbs 286 kg
APPROX. WEIGHT (CRATED) 645 lbs 293 kg 690 lbs 313 kg
GAS
AIRFLOW 600 cfm 17 cmm 375 cfm 10.6 cmm
HEAT INPUT 160,000 btu/hr 40,320 kcal/hr 140,000 btu/hr 35,280 kcal/hr
GAS INLET 1/2" 1/2"
VOLTAGE AVAILABLE 120 VOLTS OR 230 VOLTS
ELECTRIC
AIRFLOW 600 cfm 17 cmm
OVEN SIZE APPLIED VOLTAGE/PHASE
Kw
btu/hr kcal/hr 208/1ш 240/1ш 208/3ш 240/3ш 380/3ш 416/3ш 460/3ш
60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz
20 68,260 17,200 103 --- 90 --- --- --- --- --- --- 33 --- --- --- ---
24 81,910 20,640 --- --- --- --- 70 --- 62 62 --- --- --- 36 31 ---
30 102,390 25,800 --- --- --- --- 86 --- 75 75 --- --- --- 44 38 ---
STEAM*†
AIRFLOW 600 cfm 17 cmm
STEAM CONSUMPTION
BOILER HP
NORMAL LOAD
OPERATING
STEAM PRESSURE
STEAM
SUPPLY
STEAM
RETURN
144.7 lb/hr 65.7 kg/hr 4.2 125 psi 8.6 bar 1" 1"
Shaded areas are stated in metric equivalents
* Specify Air-Operated Steam Damper system or Electromechanical Steam Damper system when ordering.
† Air-Operated Steam Damper system must be provided with a clean, dry, regulated 80 psi ± 10 psi (5.52 bars ± 0.68 bars).
Air connection is 1/8" N.P.T. Air volume requirement is 0.75 cfh (0.02cmh).
