11 Chapter 2
2.2 Desktop, Swing-ARM for FPM-3150G
The FPM-3150G Series can be mounted in other ways. These is a desktop
stand for desktop use and it can also be attached to a swing-arm bracket.
2.2.1 Desktop Stand
The panel-mount bracket is attached to the rear of the FPM-3150G to
become a desktop stand. (Refer to figure 2.4) Simply detach the small
bracket at the top of the monitor by unscrewing the two screws. The
lower bracket now becomes a desktop stand bracket.
Figure 2.4: Desktop Stand for FPM-3150G
Panel Mounting
Bracket
Remove the top panel mounting bracket
that is attached on the rear side of FPM-3150G
