2-4

Chapter 2: RAID configuration

4. The Adapter Properties screen appears.

Use the arrow keys to select RAID Properties, then press .

3. The following screen appears. Select a channel and press to enter

the setup.

The numbers of the channel depend on the controller.

Esc = Exit Menu F1/Shift+1 = Help

Alt+N = Global Properties -/+ = Alter Boot Order Ins/Del = Alter Boot List

LSI Corp Config Utility v6.20.00.00 (2007.12.04)

Adapter List

Global Properties

Adapter PCI PCI PCI PCI FW Revision Status Boot

BUS Dev Fnc Slot Order

SAS1064E

02 00 00 20 1.24.00.00-IR Enabled

0

Esc = Exit Menu F1/Shift+1 = Help

Enter = Select Item -/+/Enter = Change Item

LSI Corp Config Utility v6.20.00.00 (2007.12.04)

Adapter Properties -- SAS1064E

Adapter SAS1064E

PCI Slot 20

PCI Address(Bus/Dev/Func) 02:00:00

MPT Firmware Revision 1.24.00.00-IR

SAS Address 500E0188:01111705

NVDATA Version 2D.02

Status Enabled

Boot Order 0

Boot Support [Enabled BIOS & OS]

RAID Properties

SAS Topology

Advanced Adapter Properties
