8
Button Function
( 11) ▼ ▼ Decrease the video playback at the speed of 2x, 4x 8x or 16x
( 12) ▼ ▼
Fast play the video playback at the speed of 2x, 4x 8x or 16x
(13) Stop playing / Stop recording
(14) USB backup(see 2.1.2 )
▼
▼
To move the selection to the left and right
▲
(15)
▼
To go up and down and select the items in the menu list or
change the settings
(16)
To enter the OSD Main menu / Exit from the main menu or sub-menu
display
Make a selection
(17)
Enter sub-menu
(18) REC Start video recording
i
The lower parts of buttons are not functional for the DVR system.
2.1.1 Using AB Repeat Function
AB Repeat function allow user to set a video segment from A to B point and play on
the surveillance screen until user stop. User also can backup AB Repeat file to pen
drive or external hard disk (See 2.1.2 ).
1. Press
▲
(play button) to call out the
SEARCH MODE menu to find the
recorded video that user wants to
playback.
2. Select TIME SEARCH or EVENT LIST.
- TIME SEARCH (search by date and
time): select the date and time from
where you want to begin the video
playback.
- EVENT LIST (search by condition): select from the list.
3. During the playback, press A-B to set the A point of video segment. And then,
press A-B again to set the B point of video segment. On the surveillance
screen will display “A-B” and repeat playing the AB point video segment which
user has set. To cancel AB repeat, press A-B again.
A-B
A-B
A-B
A-B
