Chapter 6 81
TravelMate 2400/3210/3220 FRU List
Picture No. Part Name and Description Part Number
Adapter
NS (Not
Show) ADAPTER 3 PIN 65W DELTA SADP-65KB
BEF 19V 3PIN AP.06501.006
ADAPTER 3 PIN 65W LITEON PA-1650-02CO
65W 3 PIN AP.06503.007
ADAPTER 3 PIN 65W HIPRO HP-
OK066B13CP 3P 65W AP.0650A.004
Battery
NS BATTERY LI-ION 6 CELLS-SANYO 2000mAH
UR18650F BT.00603.001
BATTERY LI-ION 6 CELLS-SONY 2000mAH
US18650G4 BT.00604.004
BATTERY LI-ION 6 CELLS-SANYO 2400mAH
UR18650F BT.00604.001
BATTERY LI-ION 6 CELLS-SONY 2400mAH
US18650G7 BT.00604.001
NS BATTERY LI-ION 9 CELLS-SANYO 2400mAH
UR18650F BT.00903.002
Board
The
System-
012 MODEM BOARD FOXCONN T60M845.01 54.A70V5.001
NS BLUETOOTH CARD WNC 91.BU513.002 54.A70V5.002
NS MINI PCI WIRELESS BOARD 802.11 b+g
INTEL WM3B2200/CH11 KI.CAX01.008
Upper
Case
Assembly-
251 T/P BOARD W/FFC CABLE 55.A70V5.001
