Atlantis Land WIRELESS ROUTER ADSL A02-RA210-W54 - Manual (Page 24)

ENGLISH
24
configure the PC to get an IP address from the Wireless ADSL
Router ADSL.
Please follow the steps below for PC’s network environment
installation. First of all, please check your PC’s network
components. The TCP/IP protocol stack and Ethernet network
adapter must be installed. If not, please refer to MS Windows
relative manuals.
Before you configure this Wireless ADSL Router, you need to
know the following default settings:
• Username:admin
• Password:atlantis
• IP address (192.168.1.254), Subnet Mask (255.255.255.0)
• DHCP Server: enable
• SSSID= wlan-ap, Channel=6, WEP=disable
1.6 IE Configuration
Now open IE, go to Instruments menu, select the Connections
tab and select one of the following options:
• Never use remote connection
•
Use remote connection if another network connection
isn’t available
