There is also a negative parking light output. Only one of these two
different outputs needs to be connected.
12-Pin Accessories Harness
Wire Function Description
1
BLUE
(–) AUX 3
(Trunk) output
500 ma negative output. This output can be used to control trunk release
(1-sec. pulse) or can be set to operate as a constant output as long as
buttons
Ι & ΙΙ are held pressed (for sunroof or window close).
Aux 3 (trunk) operates only when ignition is off or when the vehicle is
running under remote control.
2
BROWN
(–) Lock output
Programmable 500 mA negative output: 7/10-sec. or 4-sec. pulse.
3
GREEN
(–) Unlock
output
Programmable 500 mA negative output: 7/10-sec., 4-sec. or double 1/4-
sec. pulse.
4
WHITE/BROWN
(–) Arm output
Max. 500-ma ground signal when the doors are locked by remote. This
wire will go to ground 1/4 sec. before the lock pulse and go off 1/8 sec.
after lock. It must be connected to the OEM arm wire (usually the door
pin).
Note: The system also gives a rearm pulse on this wire after remote-start
shutdown.
5
WHITE/GREEN
(–) Disarm
output
Max. 500-ma 1-sec. ground pulse when the doors are unlocked by
remote control. Connect to the OEM disarm wire of the vehicle. Note: the
system also gives a disarm pulse on this wire before remote start.
6
BLUE/WHITE
(–) AUX 1
500 mA ground output for horn confirmation on the first or second press
of the I
button –depending on the option that was selected in the
programming menu (see page 9).
7
WHITE/ORANGE
(–) Starter Kill
(Armed output)
The unit is equipped with a selectable passive or active arming starter kill
circuit that will immobilize the vehicle when the system is armed. This
wire will provide a constant 500-ma negative output when the system is
armed (locked by remote) or if remote started. This wire should be
connected to a single pole double-throw relay (this wire will connect to pin
85, on the relay, and pin 86 will be connected to the ignition wire). A
second benefit of the starter kill is the anti-grind feature. When the
vehicle has been remote started the anti-grind prevents the starter motor
from re-engaging when the ignition key is inserted in the ignition switch
and accidentally turned to the crank
position (the starter kill output
becomes active during remote starts).
8
ORANGE
(–) Parking Light
output
Negative parking light output.
9
PURPLE
(–) External
Trigger input
The external trigger wire can be used for remote-starting the vehicle with
an external device. When the vehicle is running, triggering this input will
activate idle mode. the external trigger wire can also be used to operate
as a negative trigger with the trunk pin-switch, the key sense wire or the
door pin-switch:
9
PURPLE
(–) External
Trigger input
(cont’d)
Option 1 connects to negative trunk pin. When this wire is
programmed for trunk pin, pressing Ι & ΙΙ simultaneously will activate a
1-second disarm output. If ground (-) is detected on the trunk pin (the
trunk has been opened), an arm pulse will be sent 5 seconds after the
trunk is closes. an arm
pulse will be sent 4 seconds after buttons Ι & ΙΙ
