Wireless Multi-Function Access Point
A02-AP1-W54 Pag. 45
APPENDIX B: Technical Features
Standards IEEE 802.11b/g
IEEE 802.3u 10/100BASE-TX Fast Ethernet
Signal Type: DSSS (802.11b)
OFDM (802.11g)
Modulation: QPSK / BPSK / CCK / OFDM
LED Indicators: Power, LAN (Link/Activity), WLAN (Link)
Frequency Range 2412 MHz ~ 2462 MHz (FCC)
2412 MHz ~ 2472 MHz (ETSI)
2400 MHz ~ 2484 MHz (Japan)
Channel: 1 ~ 11 Channels (FCC)
1 ~ 13 Channels (ETSI)
1 ~ 14 Channels (Japan)
Data Encryption: 64 bit / 128 bit WEP Encryption, WPA, WPA2,
WPA-PSK, WPA2-PSK
Data Transfer Rate Fast Ethernet: 10/100Mbps
Wireless: Up to 54Mbps (with Automatic Scale
Back)
Receiver Sensitivity 54Mbps: Typical -68 dBm @10% PER
11Mbps: Typical -81 dBm @8% PER
Transmit Power 802.11g: Minimum 13dBm typically
802.11b: Minimum 15dBm typically
Transmission Range: Outdoor: 100~300M (depends on environment)
Indoor: 50~100M (depends on environment)
Network Cables 2-pair UTP/STP Cat. 3,4,5 (100 m)
Interface 1 x 10/100Mbps RJ45 port
Antenna: 1 x 2 dBi Dipole Antenna
DC inputs DC 7.5V /1A
Power Consumption 4.2W (Max)
Temperature Operating: 0 ~ 40
o
C, Storage: -10 ~ 70
o
C
Humidity Operating: 10% ~ 90%, Storage: 5% ~ 90%
Dimensions 140 x 98 x 30 mm (W x H x D) without Antenna
EMI FCC Class B, CE Mark B
