Atlantis Land A02-AP1-W54 - Manual (Page 10)

Wireless Multi-Function Access Point
A02-AP1-W54 Pag. 3
• Firmware Upgrade : the device can be upgraded to the latest firmware
through the WEB based GUI.
1.4 System Requirements
Before installing the device, your PC should meet the following:
ƒ
Intel® Pentium®III 600Mhz or compatible processor with TCP/IP stack
ƒ Iinternet Explorer V6.0 on Netscape V6.0
ƒ CDRom
1.5 Setup
The setup of the Wireless Access Point can be performed using the following
steps:
• Visually inspect the Ethernet RJ45 port connector and make sure that it is
fully plugged in to the system’s Ethernet switch/hub port.
• Fix the direction of the antennas. Try to place the AP in a position that
can best cover your wireless network. Normally, the higher you place the
antenna, the better the performance will be. The antenna’s position
enhances the receiving sensitivity.
• Visually inspect if the Power Adapter was fully plugged to the device
power jack.
