3. Electrical Connections
A wire diagram is located on the inside of the control (service) box for connection data.
a. Single-Phase (1ø) Hookup
The electrical connections on ALL single-phase (1ø) dryers are made into the junction box located at the
upper rear of the dryer. A separate circuit servicing each dryer basket (tumbler) must be provided.
S
INGLE
-P
HASE
(1
Ø
)
E
LECTRICAL
C
ONNECTION
L
EADS
Black
+
Positive
White
-
Neutral
Green
Ground
or
L2
