3D Aircraft, Non-Computer Transmitter
1. Power on your transmitter.
2. Move the throttle stick to the middle (1/2 throttle) position.
3. Hold full Left Aileron and full Down Elevator while powering on the
receiver (as shown in Figure 2). After 5 seconds, the Red and Blue LEDs
in the receiver flash.
4. Release the transmitter sticks.
5. Center both sticks, then move the throttle to the off position to save the selection.
(Figure 2)
Entering Transmitter Type by Stick Combination:
3D Aircraft:
Non-Computer Transmitters
Mode 1
IMPORTANT: Aileron and
Elevator Reversing must be set
to Normal/Normal
Mode 2
3D Aircraft, Computer Transmitter
1. Power on your transmitter.
2. Move the throttle stick to the middle (1/2 throttle) position.
3. Hold full Right Aileron and full Down Elevator while powering on the
receiver (as shown in Figure 3). After 5 seconds, the Blue and Green
LEDs in the receiver turn flash.
4. Release the transmitter sticks.
5. Center both sticks, then move the throttle to the off position to save the selection.
(Figure 3)
Entering Transmitter Type by Stick Combination:
3D Aircraft:
Computer Transmitters:
Mode 1
IMPORTANT: Aileron and
Elevator Reversing must be set
to Normal/Norma
Mode 2
