Spektrum SPMAR6400NBL User Manual

Page 7

To Change CH6 to a Reversed CH2 for Dual Ailerons or Reversed CH2

to CH6
1. Ensure the receiver and transmitter are bound

2. Turn the transmitter on

3. Move the THRO stick to the full throttle position

4. Move the Control sticks to the corresponding position to change between the

available options (see illustration)

5. Hold this position and plug the battery into the receiver

6. The LED on the receiver will turn solid within 5 seconds and the LED will flash 3

times, indicating the option is now changed

7. Disconnect the battery from the receiver

8. Turn the transmitter off

THRO/RUDD ELEV/AILE

ELEV/RUDD THRO/AILE

Rev. CH2/CH6

1. Full THRO

2. Up ELEV

3. Left AILE

Mode 1

Mode 2

To Change CH5 to X-port or X-port to CH5
When X-Port is active, CH5 and CH6 are not available; however, reversed aileron

(CH2) is still available.
1. Ensure the receiver and transmitter are bound

2. Plug the X-Port accessory or the optional servo into the X-Port/CH5 port

3. Turn the transmitter on

4. Move the THRO stick to the full throttle position

5. Move the control sticks to the corresponding position to change between the

available options (see illustration)

6. Hold this position and plug the battery into the receiver

7. The LED on the receiver will turn solid within 5 seconds and the LED will flash 3

times quickly, indicating the option is now changed

8. Disconnect the battery from the receiver

9. Turn the transmitter off

THRO/RUDD ELEV/AILE

ELEV/RUDD THRO/AILE

1. Full THRO

2. Right RUDD

CH5/X-port

Mode 1

Mode 2

Optional Support Items
Please see www.horizonhobby.com for a complete list of items.
