OM-BTT-E 5
Internal wiring for the Braising Pan is supplied complete. When you receive the unit, it
is ready for connection. A wiring diagram is located inside the console on the side of
the pan, as well as in this manual.
Your pan was performance-tested at the factory to confirm that its controls and
heating elements were functioning correctly.
Installation is as follows:
1. Set the unit in place on a level surface. The unit must be level to avoid uneven
cooking across the pan.
2. Provide the proper electric power supply as specified on the electrical
information plate. Observe local codes and/or The National Electrical Code in
accordance with ANSI/NFPA 70 - latest edition.
3. Bringing the electrical service through the entrance in the control box, make
a waterproof connection with the incoming lines. A BX connection is not
recommended. GROUND THE UNIT ELECTRICALLY AT THE TERMINAL PROVIDED.
WARNING
THE BRAISING PAN MUST BE INSTALLED
BY PERSONNEL WHO ARE QUALIFIED TO
WORK WITH ELECTRICITY. IMPROPER
INSTALLATION COULD RESULT IN PERSONAL
INJURY OR EQUIPMENT DAMAGE.
Installation
